Lunan Machine - CNC Machine Tool Manufacturer
Premier CNC Machine Tool Manufacturer

Precision CNC Lathes &
Machining Centers.

Engineered with Meehanite rigid casting, Renishaw laser-calibrated accuracy (±0.005mm), and world-class FANUC / SIEMENS controls for demanding worldwide manufacturing.

Get Instant Factory Quote Explore Machine Catalog
25+
Years Precision Heritage
±0.005mm
Positioning Accuracy
80+
Exporting Countries
24/7
Global Technical Support
Lunan Machine state of the art CNC lathe and machining center assembly workshop
ASSEMBLY BAY #3 100% FACTORY TESTED
Precision batch assembly of VMC & TCK series machines
Product Architecture

Precision Machine Tool Series

From high-speed vertical machining centers to heavy-duty universal lathes, built for zero-vibration durability and tight tolerances.

Vertical Machining Centers VMC850
VMC Series (3-Axis / 4-Axis)

Vertical Machining Centers (VMC)

Heavy-duty BT40/BT50 milling centers featuring 850mm to 1050mm worktables, high-speed spindles up to 12,000 RPM, and 24T arm tool changers.

VMC850 · VMC650 · VMC855
BT40 / BT50 Spindle up to 12,000 RPM
View Machine Models
Slant Bed CNC Lathes TCK50
TCK Series (45° Incline)

Slant Bed CNC Lathes (TCK)

45° monobloc cast iron slant bed for effortless gravity chip evacuation, hydraulic 8/12-station turrets, and high-speed bar turning.

TCK50 · TCK52 · TCK56
Hydraulic Chuck · 8/12T Turret
View Machine Models
Flat Bed CNC Lathes CK6150
CK Series (Universal Heavy)

Flat Bed CNC Lathes (CK)

Wide induction-hardened bedways (up to 550mm width) and big spindle bores (up to 105mm) for heavy-duty universal turning and pipe threading.

CK6140 · CK6150 · CK6160
Bed Width 390-550mm · Bore to 105mm
View Machine Models
High Precision Production

Flagship CNC Machinery

Our highest-demand machines trusted by automotive, aerospace, die & mold, and energy equipment builders.

All Machines (9 Models)
VMC850 Vertical Machining Center - Lunan Machine CNC
Vertical Machining Centers
Lunan Series ±0.005mm

VMC850 Vertical Machining Center

High-Rigidity BT40 Heavy-Duty Milling Center (850×500×550 mm Travel)

The VMC850 is an industry-benchmark vertical machining center engineered for high-precision molds, automotive parts, aerospace structural components, and precision batch machining. Built with a Meehanite licensed cast iron frame and high-rigidity roller linear guideways.

X/Y/Z Travel 850 × 500 × 550 mm
Table Size 1000 × 500 mm
Spindle Taper BT40 (10,000 RPM)
Spindle Power 11 kW / 15 HP
Full Technical Specs Inquire Model
TCK50 Precision Slant Bed CNC Lathe - Lunan Machine CNC
Slant Bed CNC Lathes
Lunan Series ±0.005mm

TCK50 Precision Slant Bed CNC Lathe

45° Monobloc Slant Bed Turning Center (Max Swing 500 mm, 8T Turret)

The TCK50 features an integral 45° slant bed structure delivering exceptional dynamic rigidity and ergonomic chip drop. Equipped with a high-torque spindle, Taiwan hydraulic chuck, and 8-station hydraulic tool turret for continuous production.

Max Swing Over Bed Ø500 mm
Max Turning Diameter Ø360 mm
Max Turning Length 500 mm
Spindle Bore Ø66 mm (Bar capacity Ø52 mm)
Full Technical Specs Inquire Model
CK6150 Heavy-Duty Flat Bed CNC Lathe - Lunan Machine CNC
Flat Bed CNC Lathes
Lunan Series ±0.005mm

CK6150 Heavy-Duty Flat Bed CNC Lathe

Medium-Heavy Flat Bed Lathe (Max Swing 500 mm, Bed Width 400 mm, 82 mm Bore)

Widely praised for high torque, rigid 400mm bed width, and standard Ø82mm spindle bore. Ideal for turning medium-to-large flanges, long drive shafts, agricultural tractor axles, and heavy threads.

Max Swing Over Bed Ø500 mm
Max Turning Length 1000 / 1500 / 2000 mm
Bed Width 400 mm
Spindle Bore Ø82 mm (Optional Ø105 mm)
Full Technical Specs Inquire Model
Manufacturing Standards

Why Global Manufacturers Choose Lunan Machine

Rigid structural casting, German & Japanese core kinematics, and relentless quality inspection.

Meehanite Cast Iron Structure

High-density stress-relieved Meehanite casting with dense ribbing provides outstanding vibration absorption and thermal stability during heavy roughing.

Renishaw Laser Accuracy Calibration

100% of machine axes undergo Renishaw XL-80 dual-frequency laser interferometer pitch error compensation and QC20-W ballbar dynamic testing.

World-Class Core Components

Equipped with Japanese NSK/THK bearings, Taiwanese precision ballscrews, and Schneider electrical architecture for maximum uptime.

Turnkey Global Export & Support

Seaworthy vacuum packaging, worldwide logistics dispatch, CE/ISO9001 compliance, and swift factory technical response within 12 hours.

Machining Insights

Engineering Technical Guides

In-depth procurement and engineering analysis on bed rigidity, precision calibration, and cycle optimization.

View All Guides →
Direct RFQ Channel

Consult Directly with Lunan Machine Engineers

Eliminate intermediary markups. Receive official manufacturer quotes, workpiece cycle-time simulations, and CAD fixture layout suggestions within 12 hours.

Direct RFQ Email
xiuc32860@gmail.com
Response Guarantee
Detailed Quotation within 12 Hours
Export Shipping
FOB Qingdao / Shanghai, CIF, CFR, DDU Worldwide Ports
Typical Response Time: < 12 Hours

Request a Direct Factory Quotation

Speak directly with our senior application engineers. Receive detailed price quotations, technical layout drawings, and cycle-time estimations.
