VMC855 Heavy-Duty Machining Center

Name: VMC855 Heavy-Duty Machining Center
Brand: Lunan Machine
Availability: InStock

Extra-Wide Heavy-Cutting Machining Center (850×550×550 mm Travel)

Featuring an expanded Y-axis travel of 550mm and widened base guideway span. Designed specifically for heavy roughing, large die-cast tooling, and thick plate steel machining where maximum cutting rigidity is mandatory.

Primary Engineering Parameters

X/Y/Z Travel: 850 × 550 × 550 mm

Table Size: 1050 × 550 mm

Spindle Taper: BT40 / Optional BT50

Spindle Power: 11 / 15 kW

Tool Capacity: 24-Tool Arm ATC

Max Table Load: 800 kg

Controller Options:

FANUC 0i-MF Plus SIEMENS SINUMERIK 828D GSK 25i

Request Factory Quotation Email Technical Team

VMC855 Heavy-Duty Machining Center - Complete Engineering Specifications

DIN / ISO 230-2 Standard

Worktable Dimensions	1050 × 550 mm
Max Worktable Load	800 kg
X Axis Travel	850 mm
Y Axis Travel	550 mm
Z Axis Travel	550 mm
Spindle Taper	BT40 (Standard) / BT50 (Optional)
Spindle Motor Power	11 / 15 kW
Machine Weight	5,800 kg

Standard Factory Configuration

✓ Ultra-wide column span
✓ Roller type heavy linear guideways
✓ ZF two-speed gearbox compatible
✓ Automatic lubrication system

Optional Engineered Upgrades

+ BT50 Spindle with high torque
+ Coolant through spindle (30 bar)
+ Chain type chip conveyor
+ Optical linear scale feedback

Recommended Component Applications for VMC855 Heavy-Duty Machining Center

Large injection mold cores and cavities

Stamping die shoes

Pump and valve heavy castings

Mining equipment precision parts

Typical Response Time: < 12 Hours

Request a Direct Factory Quotation

Speak directly with our senior application engineers. Receive detailed price quotations, technical layout drawings, and cycle-time estimations.
