Factory Machinery Catalog

Precision CNC Machine Tools

Engineered for structural rigidity, zero-resonance dynamic milling, and sustained micrometer repeatability. All equipment undergoes Renishaw laser interferometer calibration prior to seaworthy crating.

↓ Vertical Machining Centers (VMC) ↓ Slant Bed CNC Lathes (TCK) ↓ Flat Bed CNC Lathes (CK)

3-Axis & 4-Axis Milling

Vertical Machining Centers (VMC Series)

Heavy Meehanite cast structure, precision roller linear guideways, BT40 / BT50 spindle tapers, and 24T arm-type high-speed automatic tool changers.

VMC850 Vertical Machining Center - Lunan Machine CNC

Vertical Machining Centers

Lunan Series ±0.005mm

VMC850 Vertical Machining Center

High-Rigidity BT40 Heavy-Duty Milling Center (850×500×550 mm Travel)

The VMC850 is an industry-benchmark vertical machining center engineered for high-precision molds, automotive parts, aerospace structural components, and precision batch machining. Built with a Meehanite licensed cast iron frame and high-rigidity roller linear guideways.

X/Y/Z Travel 850 × 500 × 550 mm

Table Size 1000 × 500 mm

Spindle Taper BT40 (10,000 RPM)

Spindle Power 11 kW / 15 HP

Full Technical Specs Inquire Model

VMC650 Compact Machining Center - Lunan Machine CNC

Vertical Machining Centers

Lunan Series ±0.005mm

VMC650 Compact Machining Center

Compact High-Speed CNC Machining Center (650×400×500 mm Travel)

Engineered for small-to-medium precision parts, precision hardware, electronics tooling, and compact mold manufacturing. Small footprint, high acceleration, and economical investment with uncompromising structural rigidity.

X/Y/Z Travel 650 × 400 × 500 mm

Table Size 800 × 400 mm

Spindle Taper BT40 (8,000 / 10,000 RPM)

Spindle Power 5.5 / 7.5 kW

Full Technical Specs Inquire Model

VMC855 Heavy-Duty Machining Center - Lunan Machine CNC

Vertical Machining Centers

Lunan Series ±0.005mm

VMC855 Heavy-Duty Machining Center

Extra-Wide Heavy-Cutting Machining Center (850×550×550 mm Travel)

Featuring an expanded Y-axis travel of 550mm and widened base guideway span. Designed specifically for heavy roughing, large die-cast tooling, and thick plate steel machining where maximum cutting rigidity is mandatory.

X/Y/Z Travel 850 × 550 × 550 mm

Table Size 1050 × 550 mm

Spindle Taper BT40 / Optional BT50

Spindle Power 11 / 15 kW

Full Technical Specs Inquire Model

45° Monobloc Turning Centers

Slant Bed CNC Lathes (TCK Series)

Gravity-assisted chip removal, precision hydraulic chucks, high-torque A2-6/A2-8 spindles, and high-speed 8/12-station servo turrets.

TCK50 Precision Slant Bed CNC Lathe - Lunan Machine CNC

Slant Bed CNC Lathes

Lunan Series ±0.005mm

TCK50 Precision Slant Bed CNC Lathe

45° Monobloc Slant Bed Turning Center (Max Swing 500 mm, 8T Turret)

The TCK50 features an integral 45° slant bed structure delivering exceptional dynamic rigidity and ergonomic chip drop. Equipped with a high-torque spindle, Taiwan hydraulic chuck, and 8-station hydraulic tool turret for continuous production.

Max Swing Over Bed Ø500 mm

Max Turning Diameter Ø360 mm

Max Turning Length 500 mm

Spindle Bore Ø66 mm (Bar capacity Ø52 mm)

Full Technical Specs Inquire Model

TCK52 High-Rigidity Slant Bed CNC Lathe - Lunan Machine CNC

Slant Bed CNC Lathes

Lunan Series ±0.005mm

TCK52 High-Rigidity Slant Bed CNC Lathe

Heavy-Duty Slant Bed Turning Center (Max Swing 520 mm, Ø65 mm Bar Capacity)

Heavy-duty 45° slant bed CNC turning center with enlarged spindle bore (Ø75mm) and 10-inch chuck. Offers superior cutting capacity for medium-to-large forged and cast shafts, flanges, and high-tensile alloy turnings.

Max Swing Over Bed Ø520 mm

Max Turning Diameter Ø400 mm

Max Turning Length 600 mm

Spindle Bore Ø75 mm (Bar capacity Ø65 mm)

Full Technical Specs Inquire Model

TCK56 Heavy-Duty Slant Bed CNC Lathe - Lunan Machine CNC

Slant Bed CNC Lathes

Lunan Series ±0.005mm

TCK56 Heavy-Duty Slant Bed CNC Lathe

Heavy-Duty Industrial Slant Bed Turning Center (Max Swing 560 mm, A2-8 Spindle)

Designed for demanding heavy turning applications. With an oversized 560mm swing and reinforced monobloc bed, the TCK56 excels at processing heavy castings, oilfield equipment, and high-torque railway / automotive axle components.

Max Swing Over Bed Ø560 mm

Max Turning Diameter Ø460 mm

Max Turning Length 750 mm

Spindle Bore Ø87 mm (Bar capacity Ø75 mm)

Full Technical Specs Inquire Model

Heavy-Duty Universal Turning

Flat Bed CNC Lathes (CK Series)

Induction-hardened wide guideways and oversized spindle through-bores (82mm to 105mm) for long shafts, pipe threading, and heavy turning.

CK6140 Universal Flat Bed CNC Lathe - Lunan Machine CNC

Flat Bed CNC Lathes

Lunan Series ±0.005mm

CK6140 Universal Flat Bed CNC Lathe

Universal Precision CNC Lathe (Max Swing 400 mm, Bed Width 390 mm)

The classic workhorse for precision turning workshops. Wide induction hardened and ground bedways, large spindle bore (52mm/82mm options), easy manual chuck and tailstock operation with modern CNC automation.

Max Swing Over Bed Ø400 mm

Max Turning Length 750 / 1000 mm

Bed Width 390 mm

Spindle Bore Ø52 mm (Optional Big Bore Ø82 mm)

Full Technical Specs Inquire Model

CK6150 Heavy-Duty Flat Bed CNC Lathe - Lunan Machine CNC

Flat Bed CNC Lathes

Lunan Series ±0.005mm

CK6150 Heavy-Duty Flat Bed CNC Lathe

Medium-Heavy Flat Bed Lathe (Max Swing 500 mm, Bed Width 400 mm, 82 mm Bore)

Widely praised for high torque, rigid 400mm bed width, and standard Ø82mm spindle bore. Ideal for turning medium-to-large flanges, long drive shafts, agricultural tractor axles, and heavy threads.

Max Swing Over Bed Ø500 mm

Max Turning Length 1000 / 1500 / 2000 mm

Bed Width 400 mm

Spindle Bore Ø82 mm (Optional Ø105 mm)

Full Technical Specs Inquire Model

CK6160 Heavy-Duty Universal CNC Lathe - Lunan Machine CNC

Flat Bed CNC Lathes

Lunan Series ±0.005mm

CK6160 Heavy-Duty Universal CNC Lathe

Heavy-Duty Universal Turning Machine (Max Swing 630 mm, Bed Width 550 mm, 11 kW)

Engineered for heavy metal removal on large diameters and long workpieces. Massive 550mm bed width, 11kW motor, Ø105mm spindle bore (optional Ø130mm oil country bore), and up to 3000mm distance between centers.

Max Swing Over Bed Ø630 mm

Max Turning Length 1000 / 1500 / 2000 / 3000 mm

Bed Width 550 mm

Spindle Bore Ø105 mm (Optional Ø130 mm)

Full Technical Specs Inquire Model

OEM & Custom Engineering

Require Custom Machine Tool Configuration?

We accommodate specialized machining requests: hydraulic chuck sizes, live tooling (C/Y axes), steady rests, through-spindle coolant (CTS), and bar feeders.

Speak with a Machinery Specialist →
